PLC-602ADL Professional Leverless Duel Speed Tyre Changer

Product Code: PLC-602ADL

POA

Description

Features:

  • Tilt back column with assisting arm
  • Standardly equipped with 20mm cylinder along with variable torque adjustment bead breaker force, suitable for each RSC tyres and run-flat tyres.
  • Adopted diameter 55mm horizontal shaft. the lengthened hex bar sleeve makes the machine more robust.
  • Double-bending column is made of steel plate with 5mm thickness which assures high intensity, no deformation, protect tyres and rims safe.
  • Equipped with Al390H assist arm which adopted tyre pressing block
  • The machine adopts the parkerising bead breaker cylinder having bead break power 2800KG to bead break the tire from rim easily.
  • Standardly equipped with the assist arm which adopted tyre pressing block for the rim centring, easy and convenient operation.
  • Three positions pressing the tyres to ensure high efficiency in mounting and demounting process.
  • Leverless bar system
  • Tyre lifter optional



Specifications:

  • Outside Clamp:   11-24"
  • Rim Width:  3-14"
  • Inside Clamp:  13-26"
  • Max Wheel Diameter:  1100 mm
  • Working air pressure:  8-10bar
  • Bead breaking force: 2800kg
  • Turntable Rotation Dual Speed:  6.5/13rpm
  • Power Supply Voltage:  220V/380V
  • Motor Power:  0.75/1.1 kw
  • Noise:  <70dB
  • Packages quantity: 2
  • Packages dimensions: Main unit: 1420 x 1000 x 1100mm, Assisting arm: 1650 x 500 x 580mm
  • Packages weights: Main unit: 350kg, Assisting arm: 120kg



Freight Dimension

. Packages quantity: 2

. Packages dimensions:

Main unit: 1420 x 1000 x 1100mm,

Assisting arm: 1650 x 500 x 580mm

. Packages weights:

Main unit: 350kg,

Assisting arm: 120kg
