PLC-501 Swing Arm Tyre Changer

Product Code: PLC-501




  • Entry level swing arm tyre changer
  • Turntable protective covers as standard protect the rim from scratched by turntable and the ruler on the covers can help to clamp the rim conveniently.
  • The wearable washers as standard correspond to Europ standard to protect the personal safety when mounting the tire.
  • The control pedal assembly has the step-move function which can stop the clamp at any position to clamp the rim conveniently.
  • The hexangular shaft with 41mm and S 55 horizontal arm diameter is suitable for operation the flat and hard tire.
  • The machine adopts the parkerising bead breaker cylinder having bead break power 2500KG to bead break the tire from rim easily.
  • The machine equips the protective cover for clamps and mounting head as standard configuration to avoid damage the rim.
  • The clamp is made of special material, strong and durable.
  • The mounting head is made of special steel and lifetime warranty.
  • Standard equip inflation meter and safety valve,controllable air pressure,protection for safety.


  • Outside Clamp: 10-18"
  • Tire Width: 3-12"
  • Inside Clamp: 12-21"
  • Max Wheel Diameter: 960mm
  • Working air pressure: 8-10bar
  • Bead breaking force: 2500kg
  • Turntable Rotation Speed: 5rpm
  • Power Supply Voltage: 220V
  • Power: 85kw
  • Noise: <70dB
  • Package Size: 980 x760x950mm
  • Net weight: 180kg
  • Gross weight: 208kg
