Description
1. 48 Balancing Channels & Single Cell Balancing Design
· Provides an independent single cell balancing solution, supporting precise single-cell balancing, up to 48 battery cells simultaneously.
2. Intelligent Cell Balancing
· Supports multiple battery types, including ternary lithium(NCM/NCA), lithium iron phosphate(LiFePO4), lithium manganese oxide(LMO), and lithium titanate(LTO).
· Allows for the setting of balancing maintenance parameters, pre-selects voltage ranges based on the battery type, and automatically switches charging and discharging modes.
3. High Precision & Balancing Gain
· Supports high-precision voltage measurement for single cells, effectively improving vehicle power output and ensuring consistent battery pack performance.
4. Safety Protection & Worry-Free Process
· Provides comprehensive safety for both the device and battery.
Overcurrent Protection
Output Overcurrent Protection
Overvoltage Protection
Over-temperature Protection
5. Log Management & Data Visualization
· Supports comparison of “pre-balancing” and “post-balancing” differences, with the ability to export balancing data.
· Real-time monitoring of single cell voltages and balancing status, ensuring a clear and visualized process.
| Power Input | AC 90~264V |
| Discharge & Charge Voltage Range | 1.8~4.5V |
| Voltage Measurement Accuracy | ±(0.1%FS±2mV) |
| Discharge & Charge Current Range | 0.1~5A |
| Current Measurement Accuracy | ±(1%FS±0.05A) |
| Discharge & Charge Power | 1200W Max |
| Voltage Port | 26Pin*2 |
| Temp Port | 24Pin |
| Display | 10.1’’ TFT LCD, 1280*800 |
| PC Data Communication | TCP/IP, USB-Device |
| Wireless Communication | Wi-Fi |
| Data Storage Mode | Internal storage of device or data transfer to USB flash drive |
| Charge Mode | Constant current charging + constant voltage charging |
| Discharge Mode | CC+CA |
| Working Temperature | -5℃~45℃ |
| Dimension | 616.5 x 349.0 x 518.3 mm |
