Oscilloscope Module

Product Code: LAUNCH Oscilloscope Module

POA

Description

Featuring a new design and upgraded hardware, the LAUNCH’s new Oscilloscope Module is a versatile easy to use module that detects high level faults on various electrical components, such as sensors, actuators and circuits. By integrating with the X-431 series scan tools LAUNCH Oscilloscope Module delivers accurate and conclusive diagnostic faults that enable the shop and technician to enlarge its scan tool’s functionality.

Features

. Features the ability to record and playback high-resolution waveform data for future analysis.

. One key enable functionAllows the user to capture a particular waveform which makes the process 70% more efficient as compared to other scopes.

. Access to 23 variants of automatic measurements that are displayed on one screen for an easy switch.

. Ability to input names and characters directly by clicking on the virtual keyboard, this operation streamlines the process and contributes to 90% efficiency.

. Buffer memory up to 50M.

. Use the zoom in/out feature to review precise details

. Customisable personal system settings that can be saved as configuration files for viewing

. The self-calibration function allows optimization of the oscilloscope signal path for maximum measurement accuracy.

. Magnifies waveform math operations, such as addition, subtraction, multiplication and FFT function for high level waveform analysis.

. Multiple automotive tests that include circuits, sensors, actuators, ignition tests and more.

. Multi language user interface.

. USB Sync Data Transfer to external devices such as laptop, tablet, etc.

Compatible with LAUNCH X-431 scanners include  EUROTAB 2 and PAD V and PAD VII.



Specifications

Channels 4
Bandwidth 100MHz
Rising time ≤3.5ns (typical)
Accuracy ±3%
Input impedance 1MΩ±1.5%
Input type Single-ended, BNC connector
Input coupling DC, AC
Overload protection ±200V on single input
Timebase ranges 50ns~1ks (1 channel), 100ns~1ks (2 channels), 200ns~1ks (4 channels)
Vertical resolution 8bits
Buffer memory 50M (for 4 channels)
Power interface USB port, DC IN port
Data exchange via USB
Trigger mode Normal, Auto and Single SEQ
Advanced triggers Edge, Pulse width
